VI-J3D-IZ
RoHS
/
Package Half Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER MOD DC/DC 85V 25W
PDF
/
Inventory: 5561
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Half Brick
Technical
Operating Temperature -40°C~100°C
Packaging Bulk
Published 2010
Series VI-J00? (25W)
Size / Dimension 2.28Lx2.40W x 0.50 H 57.9mmx70.0mmx12.7mm
JESD-609 Code e0
Feature OCP, SCP
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 9
ECCN Code EAR99
Type Isolated Module
Terminal Finish TIN LEAD OVER COPPER
Applications ITE (Commercial)
Power (Watts) 25W
Max Power Dissipation 25W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number VI-J3D
JESD-30 Code R-XDMA-P9
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 90%
Voltage - Isolation 3kV
Voltage - Input (Max) 60V
Output Voltage 85V
Max Output Current 294mA
Voltage - Output 1 85V
Voltage - Input (Min) 42V
Input Voltage-Nom 48V
Trim/Adjustable Output YES
Dimensions
Height 12.7mm
Compliance
RoHS Status Non-RoHS Compliant
