VI-BN1-EU
RoHS
/
Package Full Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER MOD DC/DC 12V 200W
PDF
/
Inventory: 1668
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Full Brick
Technical
Operating Temperature -10°C~85°C
Packaging Bulk
Published 2010
Series VI-200? (200W)
Size / Dimension 4.60Lx2.40W x 0.50 H 116.8mmx61.0mmx12.7mm
JESD-609 Code e0
Feature OCP, OTP, OVP, SCP
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 9
ECCN Code EAR99
Type Isolated Module
Terminal Finish TIN LEAD OVER COPPER
Applications ITE (Commercial)
Power (Watts) 200W
Max Power Dissipation 200W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 9
JESD-30 Code R-XDMA-P9
Number of Outputs 1
Qualification Status Not Qualified
Approval Agency UL; CE; VDE; CSA; TUV; BABT
Efficiency 88%
Voltage - Isolation 3kV
Voltage - Input (Max) 76V
Output Voltage 12V
Max Output Current 16.67A
Voltage - Output 1 12V
Voltage - Input (Min) 36V
Input Voltage-Nom 48V
Trim/Adjustable Output YES
Protections THERMAL; CURRENT; OUTPUT OVER VOLTAGE
Dimensions
Height 12.7mm
Compliance
RoHS Status Non-RoHS Compliant
