VI-213-CW-F4
RoHS
/
Package Full Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER MOD DC/DC 24V 100W
PDF
/
Inventory: 951
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Full Brick
Technical
Operating Temperature -25°C~85°C
Packaging Bulk
Published 2013
Series VI-200? (100W)
Size / Dimension 4.60Lx1.86W x 1.05 H 116.8mmx47.2mmx26.7mm
JESD-609 Code e0
Feature OCP, OTP, OVP, SCP
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 9
ECCN Code EAR99
Type Isolated Module
Terminal Finish TIN LEAD OVER COPPER
Applications ITE (Commercial)
Power (Watts) 100W
Max Power Dissipation 100W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 9
JESD-30 Code R-XDMA-P9
Number of Outputs 1
Qualification Status Not Qualified
Approval Agency UL; CE; VDE; CSA; TUV; BABT
Efficiency 90%
Voltage - Isolation 3kV
Voltage - Input (Max) 32V
Output Voltage 24V
Max Output Current 4.17A
Voltage - Output 1 24V
Voltage - Input (Min) 21V
Input Voltage-Nom 24V
Trim/Adjustable Output YES
Protections THERMAL; CURRENT; OUTPUT OVER VOLTAGE
Dimensions
Height 26.67mm
Compliance
RoHS Status Non-RoHS Compliant
