RoHS
RoHS RoHS compliant
Package Half Brick
Category Power Supplies - Board Mount / DC DC Converters
Description CONVERTER MOD DC/DC 5.2V 50W
PDF
/
Inventory: 7312
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height 12.7mm

Technical

Trim/Adjustable Output YES
Input Voltage-Nom 24V
Voltage - Input (Min) 9V
Voltage - Output 1 5.2V
Max Output Current 9.62A
Output Voltage 5.2V
Voltage - Input (Max) 36V
Voltage - Isolation 3kV
Efficiency 90%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-XDMA-P9
Base Part Number VE-JVX
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 50W
Power (Watts) 50W
Applications ITE (Commercial)
Terminal Finish MATTE TIN OVER NICKEL
Type Isolated Module
ECCN Code EAR99
Number of Terminations 9
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Feature OCP, SCP
JESD-609 Code e3
Size / Dimension 2.28Lx2.40W x 0.50 H 57.9mmx70.0mmx12.7mm
Series VE-J00? (50W)
Published 2013
Packaging Bulk
Operating Temperature -55°C~100°C

Physical

Package / Case Half Brick
Mounting Type Through Hole
Mount Through Hole
