VE-J64-EX image
Favorite
VE-J64-EX image
Favorite
RoHS
RoHS RoHS compliant
Package Half Brick
Category Power Supplies - Board Mount / DC DC Converters
Description CONVERTER MOD DC/DC 48V 75W
PDF
/
Inventory: 7354
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case Half Brick

Technical

Operating Temperature -10°C~100°C
Packaging Bulk
Published 2013
Series VE-J00? (75W)
Size / Dimension 2.28Lx2.40W x 0.50 H 57.9mmx70.0mmx12.7mm
JESD-609 Code e3
Feature OCP, SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 9
ECCN Code EAR99
Type Isolated Module
Terminal Finish Matte Tin (Sn)
Applications ITE (Commercial)
Power (Watts) 75W
Max Power Dissipation 75W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number VE-J64
JESD-30 Code R-XDMA-P9
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 88%
Voltage - Isolation 3kV
Voltage - Input (Max) 400V
Output Voltage 48V
Max Output Current 1.56A
Voltage - Output 1 48V
Voltage - Input (Min) 200V
Input Voltage-Nom 300V
Trim/Adjustable Output YES

Dimensions

Height 12.7mm

Compliance

RoHS Status ROHS3 Compliant
