VE-2TH-IY
RoHS
RoHS compliant
RoHS compliantPackage Full Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER MOD DC/DC 52V 50W
PDF
/
Inventory: 5116
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Full Brick
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Published 2013
Series VE-200? (50W)
Size / Dimension 4.60Lx2.40W x 0.50 H 116.8mmx61.0mmx12.7mm
JESD-609 Code e3
Feature OCP, OTP, OVP, SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 9
ECCN Code EAR99
Type Isolated Module
Terminal Finish MATTE TIN OVER NICKEL
Applications ITE (Commercial)
Power (Watts) 50W
Max Power Dissipation 50W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XDMA-P9
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 90%
Voltage - Isolation 3kV
Voltage - Input (Max) 160V
Output Voltage 52V
Max Output Current 962mA
Voltage - Output 1 52V
Voltage - Input (Min) 66V
Input Voltage-Nom 110V
Trim/Adjustable Output YES
Dimensions
Height 12.7mm
Compliance
RoHS Status ROHS3 Compliant
