V72C8H100BF
RoHS
RoHS compliant
RoHS compliantPackage Quarter Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER MOD DC/DC 8V 100W
PDF
/
Inventory: 5016
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Quarter Brick
Technical
Operating Temperature -40°C~100°C
Packaging Bulk
Series MICRO (100W)
Size / Dimension 2.28Lx1.45W x 0.54 H 57.9mmx36.8mmx13.7mm
JESD-609 Code e4
Feature OVP, UVLO
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
ECCN Code EAR99
Type Isolated Module
Terminal Finish Gold (Au)
Applications ITE (Commercial)
Power (Watts) 100W
Additional Feature REMOTE SHUTDOWN
Subcategory Power Supply Modules
Max Power Dissipation 100W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number V72C8H100
Pin Count 7
JESD-30 Code R-XDMA-P7
Number of Outputs 1
Approval Agency UL, CSA, TUV
Efficiency 83.6%
Voltage - Isolation 3kV
Voltage - Input (Max) 110V
Output Voltage 8V
Max Output Current 12.5A
Voltage - Output 1 8V
Voltage - Input (Min) 43V
Input Voltage-Nom 72V
Trim/Adjustable Output YES
Dimensions
Height 13.716mm
Width 36.83mm
Compliance
RoHS Status ROHS3 Compliant
