V72C5C100BF3
RoHS
RoHS compliant
RoHS compliantPackage Quarter Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER MOD DC/DC 5V 100W
PDF
/
Inventory: 9551
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
ECCN Code EAR99
Type Isolated Module
Terminal Finish Gold (Au)
Applications ITE (Commercial)
Power (Watts) 100W
Additional Feature REMOTE SHUTDOWN
Subcategory Power Supply Modules
Max Power Dissipation 100W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number V72C5C100
Pin Count 7
JESD-30 Code R-XDMA-P7
Number of Outputs 1
Approval Agency UL, CSA, TUV
Efficiency 82.3%
Voltage - Isolation 3kV
Voltage - Input (Max) 110V
Output Voltage 5V
Max Output Current 20A
Voltage - Output 1 5V
Voltage - Input (Min) 43V
Input Voltage-Nom 72V
Trim/Adjustable Output YES
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature OVP, UVLO
JESD-609 Code e4
Size / Dimension 2.28Lx1.45W x 0.54 H 57.9mmx36.8mmx13.7mm
Series MICRO (100W)
Packaging Bulk
Operating Temperature -20°C~100°C
Dimensions
Height 13.716mm
Width 36.83mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Package / Case Quarter Brick
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
