V72C15E150BL3
RoHS
/
Package Quarter Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER MOD DC/DC 15V 150W
PDF
/
Inventory: 2046
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 36.83mm
Height 15.748mm
Technical
Trim/Adjustable Output YES
Input Voltage-Nom 72V
Voltage - Input (Min) 43V
Voltage - Output 1 15V
Max Output Current 10A
Output Voltage 15V
Voltage - Input (Max) 110V
Voltage - Isolation 3kV
Efficiency 85.9%
Approval Agency UL, CSA, TUV
Number of Outputs 1
JESD-30 Code R-XDMA-P7
Pin Count 7
Base Part Number V72C15E150
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 150W
Subcategory Power Supply Modules
Additional Feature REMOTE SHUTDOWN
Power (Watts) 150W
Applications ITE (Commercial)
Terminal Finish Tin/Lead (Sn/Pb)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Feature OVP, UVLO
JESD-609 Code e0
Size / Dimension 2.28Lx1.45W x 0.62 H 57.9mmx36.8mmx15.7mm
Series MICRO (150W)
Packaging Bulk
Operating Temperature -10°C~100°C
Physical
Package / Case Quarter Brick
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
