V48C5E50BL2
RoHS
/
Package Quarter Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER MOD DC/DC 5V 50W
PDF
/
Inventory: 4495
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 36.83mm
Length 57.912mm
Height 15.748mm
Technical
Isolation Isolated
Max Input Voltage 75V
Min Input Voltage 36V
Output Power 50W
Current - Output (Max) 10A
Voltage - Input (Min) 36V
Voltage - Output 1 5V
Max Output Current 10A
Output Voltage 5V
Voltage - Input (Max) 75V
Voltage - Isolation 3kV
Efficiency 84.5%
Number of Outputs 1
Base Part Number V48C5E50
Max Power Dissipation 50W
Power (Watts) 50W
Applications ITE (Commercial)
Min Operating Temperature -10°C
Max Operating Temperature 100°C
Type Isolated Module
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature OVP, UVLO
Size / Dimension 2.28Lx1.45W x 0.62 H 57.9mmx36.8mmx15.7mm
Series MICRO (50W)
Published 2012
Packaging Bulk
Operating Temperature -10°C~100°C
Physical
Package / Case Quarter Brick
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
