V48C24E75BG3
RoHS
RoHS compliant
RoHS compliantPackage Quarter Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER MOD DC/DC 24V 75W
PDF
/
Inventory: 1992
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Quarter Brick
Technical
Operating Temperature -10°C~100°C
Packaging Bulk
Series MICRO (75W)
Size / Dimension 2.28Lx1.45W x 0.62 H 57.9mmx36.8mmx15.7mm
JESD-609 Code e4
Feature OVP, UVLO
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
ECCN Code EAR99
Type Isolated Module
Terminal Finish Gold (Au)
Applications ITE (Commercial)
Power (Watts) 75W
Additional Feature REMOTE SHUTDOWN
Subcategory Power Supply Modules
Max Power Dissipation 75W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number V48C24E75
Pin Count 7
JESD-30 Code R-XDMA-P7
Number of Outputs 1
Qualification Status Not Qualified
Approval Agency UL, CSA, TUV
Efficiency 87.3%
Voltage - Isolation 3kV
Voltage - Input (Max) 75V
Output Voltage 24V
Max Output Current 3.13A
Voltage - Output 1 24V
Voltage - Input (Min) 36V
Input Voltage-Nom 48V
Trim/Adjustable Output YES
Dimensions
Height 15.748mm
Width 36.83mm
Compliance
RoHS Status ROHS3 Compliant
