V375C5C100B
RoHS
/
Package Quarter Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER MOD DC/DC 5V 100W
PDF
/
Inventory: 6033
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Quarter Brick
Technical
Operating Temperature -20°C~100°C
Packaging Bulk
Series MICRO (100W)
Size / Dimension 2.28Lx1.45W x 0.57 H 57.9mmx36.8mmx14.5mm
JESD-609 Code e0
Feature OVP, UVLO
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
ECCN Code EAR99
Type Isolated Module
Terminal Finish TIN LEAD
Applications ITE (Commercial)
Power (Watts) 100W
Subcategory Power Supply Modules
Max Power Dissipation 100W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number V375C5C100
Pin Count 7
JESD-30 Code R-XDFM-P7
Number of Outputs 1
Qualification Status Not Qualified
Approval Agency CSA, UL
Efficiency 81.8%
Voltage - Isolation 3kV
Voltage - Input (Max) 425V
Output Voltage 5V
Max Output Current 20A
Voltage - Output 1 5V
Voltage - Input (Min) 250V
Input Voltage-Nom 375V
Trim/Adjustable Output YES
Dimensions
Height 14.478mm
Width 36.83mm
Compliance
RoHS Status Non-RoHS Compliant
