V375B5E150BS
RoHS
RoHS compliant
RoHS compliantPackage 9-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER MOD DC/DC 5V 150W
PDF
/
Inventory: 7422
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 9-DIP Module
Technical
Operating Temperature -10°C~100°C
Packaging Bulk
Series MINI (150W)
Size / Dimension 2.28Lx2.20W x 0.50 H 57.9mmx55.9mmx12.7mm
JESD-609 Code e4
Feature OVP, UVLO
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 9
ECCN Code EAR99
Type Isolated Module
Terminal Finish GOLD
Applications ITE (Commercial)
Power (Watts) 150W
Additional Feature REMOTE SHUTDOWN
Subcategory Power Supply Modules
Max Power Dissipation 150W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number V375B5E150
Pin Count 9
JESD-30 Code R-XDFM-P9
Number of Outputs 1
Qualification Status Not Qualified
Approval Agency UL, TUV, CE
Efficiency 83.4%
Voltage - Isolation 3kV
Voltage - Input (Max) 425V
Output Voltage 5V
Max Output Current 30A
Voltage - Output 1 5V
Voltage - Input (Min) 250V
Input Voltage-Nom 375V
Trim/Adjustable Output YES
Dimensions
Height 13.716mm
Width 55.88mm
Compliance
RoHS Status ROHS3 Compliant
