V300A28M400BF
RoHS
RoHS compliant
RoHS compliantPackage Full Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER MOD DC/DC 28V 400W
PDF
/
Inventory: 4279
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Full Brick
Technical
Operating Temperature -55°C~100°C
Packaging Bulk
Series Maxi (400W)
Size / Dimension 4.60Lx2.20W x 0.54 H 116.8mmx55.9mmx13.7mm
JESD-609 Code e4
Feature OVP, UVLO
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 9
ECCN Code EAR99
Type Isolated Module
Terminal Finish Gold (Au)
Applications ITE (Commercial)
Power (Watts) 400W
Additional Feature REMOTE SHUTDOWN
Subcategory Power Supply Modules
Max Power Dissipation 400W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number V300A28M400
Pin Count 9
JESD-30 Code R-XDFM-P9
Number of Outputs 1
Qualification Status Not Qualified
Approval Agency UL, TUV, CE
Efficiency 87%
Voltage - Isolation 3kV
Voltage - Input (Max) 375V
Output Voltage 28V
Max Output Current 14.28A
Voltage - Output 1 28V
Voltage - Input (Min) 180V
Input Voltage-Nom 300V
Trim/Adjustable Output YES
Dimensions
Height 13.716mm
Width 55.88mm
Compliance
RoHS Status ROHS3 Compliant
