V28C5C50BL2
RoHS
/
Package Quarter Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER MOD DC/DC 5V 50W
PDF
/
Inventory: 2251
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Efficiency 77%
Voltage - Isolation 3kV
Voltage - Input (Max) 36V
Output Voltage 5V
Max Output Current 10A
Voltage - Output 1 5V
Voltage - Input (Min) 9V
Input Voltage-Nom 28V
Trim/Adjustable Output YES
Approval Agency CE, CSA, TUV, UL
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-XDMA-P7
Pin Count 7
Base Part Number V28C5C50
Reach Compliance Code not_compliant
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 50W
Power (Watts) 50W
Applications ITE (Commercial)
Terminal Finish Tin/Lead (Sn/Pb)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Feature OVP, UVLO
JESD-609 Code e0
Size / Dimension 2.28Lx1.45W x 0.62 H 57.9mmx36.8mmx15.7mm
Series MICRO (50W)
Published 2012
Packaging Bulk
Operating Temperature -20°C~100°C
Dimensions
Height 15.748mm
Width 36.83mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
Physical
Package / Case Quarter Brick
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
