V28B48C150B
RoHS
/
Package 9-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER MOD DC/DC 48V 150W
PDF
/
Inventory: 2519
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 55.88mm
Length 57.9mm
Height 13.716mm
Technical
Trim/Adjustable Output YES
Input Voltage-Nom 24V
Voltage - Input (Min) 9V
Voltage - Output 1 48V
Max Output Current 3.13A
Output Voltage 48V
Voltage - Input (Max) 36V
Voltage - Isolation 3kV
Efficiency 81.8%
Number of Outputs 1
JESD-30 Code R-XDMA-P9
Pin Count 9
Base Part Number V28B48C150
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 150W
Power (Watts) 150W
Applications ITE (Commercial)
Terminal Finish TIN LEAD
Type Isolated Module
ECCN Code EAR99
Number of Terminations 9
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code no
Feature OVP, UVLO
JESD-609 Code e0
Size / Dimension 2.28Lx2.20W x 0.50 H 57.9mmx55.9mmx12.7mm
Series MINI (150W)
Packaging Bulk
Operating Temperature -20°C~100°C
Physical
Package / Case 9-DIP Module
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
