V24C15C150BG2

Vicor Corporation
RoHS
RoHS RoHS compliant
Package Quarter Brick
Category Power Supplies - Board Mount / DC DC Converters
Description CONVERTER MOD DC/DC 15V 150W
PDF
/
Inventory: 6214
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case Quarter Brick

Technical

Operating Temperature -20°C~100°C
Packaging Bulk
Series MICRO (150W)
Size / Dimension 2.28Lx1.45W x 0.62 H 57.9mmx36.8mmx15.7mm
JESD-609 Code e4
Feature OVP, UVLO
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
ECCN Code EAR99
Type Isolated Module
Terminal Finish Gold (Au)
Applications ITE (Commercial)
Power (Watts) 150W
Max Power Dissipation 150W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number V24C15C150
JESD-30 Code R-XDFM-P7
Number of Outputs 1
Efficiency 89.3%
Voltage - Isolation 3kV
Voltage - Input (Max) 36V
Output Voltage 15V
Max Output Current 10A
Voltage - Output 1 15V
Voltage - Input (Min) 18V
Input Voltage-Nom 24V
Trim/Adjustable Output YES

Dimensions

Height 15.748mm

Compliance

RoHS Status ROHS3 Compliant
