V24C12M150B2
RoHS
/
Package Quarter Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER MOD DC/DC 12V 150W
PDF
/
Inventory: 9466
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Quarter Brick
Technical
Operating Temperature -55°C~100°C
Packaging Bulk
Series MICRO (150W)
Size / Dimension 2.28Lx1.45W x 0.54 H 57.9mmx36.8mmx13.7mm
JESD-609 Code e0
Feature OVP, UVLO
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
ECCN Code EAR99
Type Isolated Module
Terminal Finish Tin/Lead (Sn/Pb)
Applications ITE (Commercial)
Power (Watts) 150W
Max Power Dissipation 150W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-XDFM-P7
Number of Outputs 1
Efficiency 88.4%
Voltage - Isolation 3kV
Voltage - Input (Max) 36V
Output Voltage 12V
Max Output Current 12.5A
Voltage - Output 1 12V
Voltage - Input (Min) 18V
Input Voltage-Nom 24V
Trim/Adjustable Output YES
Dimensions
Height 13.716mm
Compliance
RoHS Status Non-RoHS Compliant
