V150C8T100BL2
RoHS
/
Package Quarter Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER MOD DC/DC 8V 100W
PDF
/
Inventory: 8988
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Quarter Brick
Technical
Operating Temperature -40°C~100°C
Packaging Bulk
Series MICRO (100W)
Size / Dimension 2.28Lx1.45W x 0.65 H 57.9mmx36.8mmx16.5mm
JESD-609 Code e0
Feature OVP, UVLO
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
ECCN Code EAR99
Type Isolated Module
Terminal Finish Tin/Lead (Sn/Pb)
Applications ITE (Commercial)
Power (Watts) 100W
Additional Feature REMOTE SHUTDOWN
Subcategory Power Supply Modules
Max Power Dissipation 100W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 7
JESD-30 Code R-XDMA-P7
Number of Outputs 1
Approval Agency UL, CSA, TUV
Efficiency 84%
Voltage - Isolation 3kV
Voltage - Input (Max) 200V
Output Voltage 8V
Max Output Current 12.5A
Voltage - Output 1 8V
Voltage - Input (Min) 100V
Input Voltage-Nom 150V
Trim/Adjustable Output YES
Dimensions
Height 16.51mm
Width 36.83mm
Compliance
RoHS Status Non-RoHS Compliant
