V150C15E150BS
RoHS
RoHS compliant
RoHS compliantPackage Quarter Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER MOD DC/DC 15V 150W
PDF
/
Inventory: 5542
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 36.83mm
Height 13.208mm
Technical
Trim/Adjustable Output YES
Input Voltage-Nom 150V
Voltage - Input (Min) 100V
Voltage - Output 1 15V
Max Output Current 10A
Output Voltage 15V
Voltage - Input (Max) 200V
Voltage - Isolation 3kV
Efficiency 87.9%
Approval Agency UL, CSA, TUV
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-XDMA-P7
Pin Count 7
Base Part Number V150C15E150
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 150W
Subcategory Power Supply Modules
Additional Feature REMOTE SHUTDOWN
Power (Watts) 150W
Applications ITE (Commercial)
Terminal Finish GOLD
Type Isolated Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
Feature OVP, UVLO
JESD-609 Code e4
Size / Dimension 2.28Lx1.45W x 0.52 H 57.9mmx36.8mmx13.2mm
Series MICRO (150W)
Packaging Bulk
Operating Temperature -10°C~100°C
Physical
Package / Case Quarter Brick
Mounting Type Through Hole
Mount Through Hole
