V110C24E100BL3
RoHS
/
Package Quarter Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER MOD DC/DC 24V 100W
PDF
/
Inventory: 2703
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Quarter Brick
Technical
Operating Temperature -10°C~100°C
Packaging Bulk
Series MICRO (100W)
Size / Dimension 2.28Lx1.45W x 0.62 H 57.9mmx36.8mmx15.7mm
Feature OVP, UVLO
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 100W
Additional Feature SEATED HT CALCULATED
Max Power Dissipation 100W
Technology HYBRID
Terminal Position UNSPECIFIED
Terminal Form PIN/PEG
Number of Functions 1
Reach Compliance Code not_compliant
Base Part Number V110C24E100
Pin Count 7
JESD-30 Code R-PXMA-P7
Number of Outputs 1
Qualification Status Not Qualified
Approval Agency CE, TUV, UL
Efficiency 86.3%
Voltage - Isolation 3kV
Voltage - Input (Max) 154V
Output Voltage 24V
Max Output Current 4.17A
Voltage - Output 1 24V
Voltage - Input (Min) 66V
Input Voltage-Nom 110V
Protections OUTPUT OVER VOLTAGE
Dimensions
Height 15.748mm
Length 57.9mm
Width 36.8mm
Compliance
RoHS Status Non-RoHS Compliant
