DCM3623TA5N53B4T00
RoHS
RoHS compliant
RoHS compliantPackage 9-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 48V 240W
PDF
/
Buying Options
Total Price: USD $206.28
Unit Price: USD $206.2808
≥1 USD $206.2808
≥10 USD $163.85688
≥100 USD $149.503904
≥500 USD $146.421088
Inventory: 90
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Current - Output (Max) 5A
Voltage - Input (Min) 43V
Voltage - Output 1 48V
Voltage - Input (Max) 154V
Voltage - Isolation 3kV
Efficiency 90.7%
Number of Outputs 1
Power (Watts) 240W
Applications ITE (Commercial)
Type Isolated Module
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature OCP, OTP, OVP, SCP, UVLO
Size / Dimension 1.52Lx0.90W x 0.28 H 38.72mmx22.8mmx7.2mm
Series VI Chip? DCM? (240W)
Packaging Box
Operating Temperature -40°C~125°C
Physical
Package / Case 9-DIP Module
Mounting Type Through Hole
Supply Chain
Factory Lead Time 16 Weeks
