TSR 2-0525
RoHS
RoHS compliant
RoHS compliantPackage 3-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 2.5V 5W
PDF
/
Buying Options
Total Price: USD $11.71
Unit Price: USD $11.71128
≥1 USD $11.71128
≥10 USD $11.04838
≥100 USD $10.423
≥500 USD $9.83302
≥1000 USD $9.27643
Inventory: 7745
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Technical
Total Power Output-Max 5W
Current - Output (Max) 2A
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Voltage - Input (Min) 3.8V
Voltage - Output 1 2.5V
Output Voltage 2.5V
Voltage - Input (Max) 5.5V
Efficiency 95%
Number of Outputs 1
JESD-30 Code R-PSMA-T3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Power (Watts) 5W
Applications ITE (Commercial)
Type Linear Regulator Replacement
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature OCP, SCP
Size / Dimension 0.55Lx0.30W x 0.40 H 14.0mmx7.5mmx10.1mm
Series TSR 2
Operating Temperature -40°C~85°C With Derating
Physical
Surface Mount NO
Package / Case 3-SIP Module
Mounting Type Through Hole
Supply Chain
Factory Lead Time 13 Weeks
