TSR 2-0515
RoHS
RoHS compliant
RoHS compliantPackage 3-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 1.5V 3W
PDF
/
Buying Options
Total Price: USD $10.23
Unit Price: USD $10.22701
≥1 USD $10.22701
≥10 USD $9.64812
≥100 USD $9.102
Inventory: 62
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mounting Type Through Hole
Package / Case 3-SIP Module
Surface Mount NO
Technical
Operating Temperature -40°C~85°C With Derating
Series TSR 2
Size / Dimension 0.55Lx0.30W x 0.40 H 14.0mmx7.5mmx10.1mm
Feature OCP, SCP
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 3
ECCN Code EAR99
Type Linear Regulator Replacement
Applications ITE (Commercial)
Power (Watts) 3W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PSMA-T3
Number of Outputs 1
Efficiency 91%
Voltage - Input (Max) 5.5V
Output Voltage 1.5V
Voltage - Output 1 1.5V
Voltage - Input (Min) 3V
Input Voltage-Nom 5V
Trim/Adjustable Output NO
Current - Output (Max) 2A
Total Power Output-Max 3W
Dimensions
Width 7.5mm
Compliance
RoHS Status ROHS3 Compliant
