TRS 2-4823
RoHS
RoHS compliant
RoHS compliantPackage 7-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-15V 2W
PDF
/
Buying Options
Total Price: USD $17.59
Unit Price: USD $17.58752
≥1 USD $17.58752
≥10 USD $16.592
≥100 USD $15.65283
≥500 USD $14.76682
≥1000 USD $13.93096
Inventory: 6335
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 11.3mm
Length 11.9mm
Height Seated (Max) 8.5mm
Height 8.5mm
Technical
Warm-up Time 0.005 s
Total Power Output-Max 2W
Control Mode VOLTAGE-MODE
Voltage - Output 2 -15V
Current - Output (Max) 67mA 67mA
Trim/Adjustable Output NO
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Voltage - Output 1 15V
Output Voltage 15V
Voltage - Input (Max) 75V
Voltage - Isolation 1.6kV
Efficiency 80%
Approval Agency UL, EN, IEC
Number of Outputs 2
JESD-30 Code R-PDMA-F7
Number of Functions 1
Terminal Form FLAT
Terminal Position DUAL
Technology HYBRID
Power (Watts) 2W
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 7
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Active
Feature SCP
Size / Dimension 0.47Lx0.44W x 0.31 H 11.9mmx11.3mmx8.0mm
Series TRS 2 (2W)
Operating Temperature -40°C~90°C With Derating
Physical
Surface Mount YES
Package / Case 7-SMD Module
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 13 Weeks
