TRN 3-0515
RoHS
RoHS compliant
RoHS compliantPackage 5-SIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 24V 3W
PDF
/
Buying Options
Total Price: USD $17.21
Unit Price: USD $17.2128
≥1 USD $17.2128
≥10 USD $16.95144
≥100 USD $16.686208
≥500 USD $15.891744
≥1000 USD $14.567432
≥3000 USD $14.30257
Inventory: 231
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mounting Type Through Hole
Package / Case 5-SIP Module, 4 Leads
Surface Mount NO
Technical
Operating Temperature -40°C~85°C
Series TRN 3 (3W)
Size / Dimension 0.47Lx0.30W x 0.43 H 11.9mmx7.7mmx11.0mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 5
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 3W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PSMA-T5
Number of Outputs 1
Efficiency 80%
Voltage - Isolation 1.6kV
Voltage - Input (Max) 13.2V
Output Voltage 24V
Voltage - Output 1 24V
Voltage - Input (Min) 4.5V
Input Voltage-Nom 9V
Trim/Adjustable Output NO
Current - Output (Max) 125mA
Total Power Output-Max 3W
Dimensions
Width 7.7mm
Compliance
RoHS Status ROHS3 Compliant
