TRN 1-0513
RoHS
RoHS compliant
RoHS compliantPackage 5-SIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 15V 1.1W
PDF
/
Buying Options
Total Price: USD $8.98
Unit Price: USD $8.976
≥1 USD $8.976
≥10 USD $8.44888
≥100 USD $8.319168
≥500 USD $8.059216
≥1000 USD $7.279272
≥3000 USD $7.149296
Inventory: 89
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mounting Type Through Hole
Package / Case 5-SIP Module, 4 Leads
Surface Mount NO
Technical
Operating Temperature -40°C~90°C
Series TRN 1 (1W)
Size / Dimension 0.47Lx0.30W x 0.43 H 11.9mmx7.7mmx11.0mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 5
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 1.1W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PSMA-T5
Number of Outputs 1
Efficiency 82%
Voltage - Isolation 1.6kV
Voltage - Input (Max) 13.2V
Output Voltage 15V
Voltage - Output 1 15V
Voltage - Input (Min) 4.5V
Input Voltage-Nom 9V
Trim/Adjustable Output NO
Current - Output (Max) 70mA
Total Power Output-Max 1W
Dimensions
Width 7.7mm
Compliance
RoHS Status ROHS3 Compliant
