TRA 3-1219

Traco Power
RoHS
RoHS RoHS compliant
Package 6-SIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description DC DC CONVERTER 9V 3W
PDF
/
Buying Options
Total Price: USD $12.83
Unit Price: USD $12.83488
≥1 USD $12.83488
≥10 USD $12.10838
≥100 USD $11.423
≥500 USD $10.77642
≥1000 USD $10.16643
Inventory: 3258
Minimum: 1
-
+

Technical Details

Technical

Total Power Output-Max 2.997W
Current - Output (Max) 333mA
Trim/Adjustable Output NO
Input Voltage-Nom 12V
Voltage - Input (Min) 10.8V
Voltage - Output 1 9V
Output Voltage 9V
Voltage - Input (Max) 13.2V
Voltage - Isolation 1kV
Efficiency 87.5%
Number of Outputs 1
JESD-30 Code R-PSMA-T4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Power (Watts) 3W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature SCP
Size / Dimension 0.77Lx0.30W x 0.40 H 19.5mmx7.6mmx10.2mm
Series TRA 3 (3W)
Published 2013
Operating Temperature -40°C~95°C With Derating

Dimensions

Width 7.6mm

Compliance

RoHS Status ROHS3 Compliant

Physical

Surface Mount NO
Package / Case 6-SIP Module, 4 Leads
Mounting Type Through Hole

Supply Chain

Factory Lead Time 11 Weeks
