TRA 3-1213
RoHS
RoHS compliant
RoHS compliantPackage 6-SIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 15V 3W
PDF
/
Buying Options
Total Price: USD $12.83
Unit Price: USD $12.83264
≥1 USD $12.83264
≥10 USD $12.10626
≥100 USD $11.421
≥500 USD $10.77453
≥1000 USD $10.16465
Inventory: 6296
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.6mm
Technical
Total Power Output-Max 3W
Current - Output (Max) 200mA
Trim/Adjustable Output NO
Input Voltage-Nom 12V
Voltage - Input (Min) 10.8V
Voltage - Output 1 15V
Output Voltage 15V
Voltage - Input (Max) 13.2V
Voltage - Isolation 1kV
Efficiency 89%
Number of Outputs 1
JESD-30 Code R-PSMA-T4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Power (Watts) 3W
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 4
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature SCP
Size / Dimension 0.77Lx0.30W x 0.40 H 19.5mmx7.6mmx10.2mm
Series TRA 3 (3W)
Published 2013
Operating Temperature -40°C~95°C With Derating
Physical
Surface Mount NO
Package / Case 6-SIP Module, 4 Leads
Mounting Type Through Hole
Supply Chain
Factory Lead Time 11 Weeks
