TRA 1-2412

Traco Power
RoHS
RoHS RoHS compliant
Package 6-SIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description DC DC CONVERTER 12V 1W
PDF
/
Inventory: 9311
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 11 Weeks

Physical

Mounting Type Through Hole
Package / Case 6-SIP Module, 4 Leads
Surface Mount NO

Technical

Operating Temperature -40°C~95°C With Derating
Published 2011
Series TRA 1 (1W)
Size / Dimension 0.77Lx0.28W x 0.40 H 19.5mmx7.1mmx10.2mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 5
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 1W
Technology HYBRID
Terminal Position SINGLE
Terminal Form PIN/PEG
Number of Functions 1
Terminal Pitch 2.54mm
JESD-30 Code R-PSMA-P5
Number of Outputs 1
Efficiency 87.5%
Voltage - Isolation 1kV
Voltage - Input (Max) 26.4V
Output Voltage 12V
Voltage - Output 1 12V
Voltage - Input (Min) 21.6V
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Current - Output (Max) 84mA
Total Power Output-Max 1W

Compliance

RoHS Status ROHS3 Compliant
