TRA 1-1223 image
Favorite
TRA 1-1223 image
Favorite

TRA 1-1223

Traco Power
RoHS
RoHS RoHS compliant
Package 6-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description DC DC CONVERTER +/-15V 1W
PDF
/
Inventory: 9613
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 11 Weeks

Physical

Mounting Type Through Hole
Package / Case 6-SIP Module, 5 Leads
Surface Mount NO

Technical

Operating Temperature -40°C~95°C With Derating
Published 2011
Series TRA 1 (1W)
Size / Dimension 0.77Lx0.24W x 0.40 H 19.5mmx6.1mmx10.2mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 5
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 1W
Technology HYBRID
Terminal Position SINGLE
Terminal Form PIN/PEG
Number of Functions 1
JESD-30 Code R-PSMA-P5
Number of Outputs 2
Efficiency 87.5%
Voltage - Isolation 1kV
Voltage - Input (Max) 13.2V
Output Voltage 15V
Voltage - Output 1 15V
Voltage - Input (Min) 10.8V
Input Voltage-Nom 12V
Trim/Adjustable Output NO
Current - Output (Max) 34mA 34mA
Voltage - Output 2 -15V
Total Power Output-Max 1W

Dimensions

Length 19.5mm
Width 6.1mm

Compliance

RoHS Status ROHS3 Compliant
