TOS 06-12SIL

Traco Power
RoHS
RoHS RoHS compliant
Package 5-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description DC DC CONVERTER 0.75-5V 30W
PDF
/
Buying Options
Total Price: USD $19.71
Unit Price: USD $19.712
≥1 USD $19.712
≥10 USD $18.82848
≥100 USD $18.534208
≥500 USD $17.65148
≥1000 USD $16.18056
≥3000 USD $15.886411
Inventory: 125
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 13 Weeks

Physical

Mounting Type Through Hole
Package / Case 5-SIP Module
Surface Mount NO

Technical

Operating Temperature -40°C~85°C
Published 2006
Series TOS
Size / Dimension 0.90Lx0.23W x 0.40 H 22.9mmx6.0mmx10.2mm
Feature Remote On/Off, OCP, OTP, SCP
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 5
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Power (Watts) 30W
Additional Feature SEATED HGT-NOM
Technology HYBRID
Terminal Position SINGLE
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) 265
Number of Functions 1
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) 10
JESD-30 Code R-XSMA-P5
Number of Outputs 1
Efficiency 89%
Voltage - Input (Max) 14V
Voltage - Output 1 0.75V~5V
Voltage - Input (Min) 8.3V
Input Voltage-Nom 12V
Trim/Adjustable Output YES
Current - Output (Max) 6A
Protections OUTPUT OVER CURRENT; THERMAL
Total Power Output-Max 30W
Warm-up Time 0.008 s

Dimensions

Length 22.9mm
Width 6mm

Compliance

RoHS Status ROHS3 Compliant
