TON 15-4812
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 12V 16W
PDF
/
Inventory: 1692
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mounting Type Through Hole
Package / Case 6-DIP Module
Surface Mount NO
Technical
Operating Temperature -40°C~85°C With Derating
Published 2011
Series TON 15 (15W)
Size / Dimension 1.10Lx0.94W x 0.33 H 27.9mmx23.9mmx8.5mm
Feature Remote On/Off, OCP, OVP, SCP, UVLO
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 6
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 16W
Technology HYBRID
Terminal Position DUAL
Peak Reflow Temperature (Cel) 245
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) 10
JESD-30 Code R-XDMA-T6
Number of Outputs 1
Efficiency 86%
Voltage - Isolation 2.25kV
Voltage - Input (Max) 75V
Output Voltage 12V
Voltage - Output 1 12V
Voltage - Input (Min) 36V
Input Voltage-Nom 48V
Trim/Adjustable Output YES
Current - Output (Max) 1.3A
Dimensions
Height Seated (Max) 8.85mm
Length 27.94mm
Width 23.88mm
Compliance
RoHS Status ROHS3 Compliant
