TMV 2-05159HI
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 4 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 15V -9V 2W
PDF
/
Buying Options
Total Price: USD $11.71
Unit Price: USD $11.70791
≥1 USD $11.70791
≥10 USD $11.0452
≥100 USD $10.42
Inventory: 40
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Length 19.5mm
Height Seated (Max) 10.7mm
Technical
Total Power Output-Max 2W
Voltage - Output 2 -9V
Current - Output (Max) 66mA 110mA
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Voltage - Output 1 15V
Output Voltage 15V
Voltage - Input (Max) 5.5V
Voltage - Isolation 5.2kV
Efficiency 80%
Number of Outputs 2
JESD-30 Code R-XSMA-T5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Additional Feature ALSO VOUT=(-9 VOLT)
Power (Watts) 2W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature SCP
Size / Dimension 0.77Lx0.30W x 0.40 H 19.5mmx7.5mmx10.2mm
Series TMV 2HI (2W)
Published 2015
Operating Temperature -40°C~85°C With Derating
Physical
Surface Mount NO
Package / Case 7-SIP Module, 4 Leads
Mounting Type Through Hole
Supply Chain
Factory Lead Time 11 Weeks
