TMV 1209DHI
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-9V 1W
PDF
/
Inventory: 8724
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Through Hole
Package / Case 7-SIP Module, 5 Leads
Technical
Operating Temperature -40°C~95°C With Derating
Published 2014
Series TMV-HI (1W)
Size / Dimension 0.77Lx0.30W x 0.40 H 19.5mmx7.5mmx10.2mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 1W
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Outputs 2
Efficiency 76%
Voltage - Isolation 5.2kV
Voltage - Input (Max) 13.2V
Voltage - Output 1 9V
Voltage - Input (Min) 10.8V
Current - Output (Max) 56mA 56mA
Voltage - Output 2 -9V
Compliance
RoHS Status ROHS3 Compliant
