TMV 1205D
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-5V 1W
PDF
/
Buying Options
Total Price: USD $4.64
Unit Price: USD $4.63597
≥1 USD $4.63597
≥10 USD $4.37356
≥100 USD $4.126
Inventory: 78
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 19.5mm
Technical
Voltage - Output 2 -5V
Current - Output (Max) 100mA 100mA
Trim/Adjustable Output NO
Input Voltage-Nom 12V
Voltage - Input (Min) 12V
Voltage - Output 1 5V
Output Voltage 5V
Voltage - Input (Max) 13.2V
Voltage - Isolation 3kV
Efficiency 66%
Qualification Status Not Qualified
Number of Outputs 2
JESD-30 Code R-XSMA-P5
Pin Count 7/5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position SINGLE
Technology HYBRID
Subcategory Other Analog ICs
Power (Watts) 1W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 0.77Lx0.24W x 0.40 H 19.5mmx6.1mmx10.2mm
Series TMV (1W)
Published 2015
Operating Temperature -40°C~85°C With Derating
Physical
Surface Mount NO
Package / Case 7-SIP Module, 5 Leads
Mounting Type Through Hole
Supply Chain
Factory Lead Time 11 Weeks
