TMV 0509DHI
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-9V 1W
PDF
/
Buying Options
Total Price: USD $8.98
Unit Price: USD $8.976
≥1 USD $8.976
≥10 USD $8.66624
≥100 USD $8.53248
≥500 USD $8.26584
≥1000 USD $7.46592
≥3000 USD $7.332582
Inventory: 58
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Voltage - Output 2 -9V
Current - Output (Max) 56mA 56mA
Voltage - Input (Min) 4.5V
Voltage - Output 1 9V
Voltage - Input (Max) 5.5V
Voltage - Isolation 5.2kV
Efficiency 75%
Number of Outputs 2
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Power (Watts) 1W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature SCP
Size / Dimension 0.77Lx0.30W x 0.40 H 19.5mmx7.5mmx10.2mm
Series TMV-HI (1W)
Published 2014
Operating Temperature -40°C~95°C With Derating
Physical
Package / Case 7-SIP Module, 5 Leads
Mounting Type Through Hole
Supply Chain
Factory Lead Time 11 Weeks
