TMV 0505DHI
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-5V 1W
PDF
/
Buying Options
Total Price: USD $8.98
Unit Price: USD $8.976
≥1 USD $8.976
≥10 USD $8.66624
≥100 USD $8.53248
≥500 USD $8.26584
≥1000 USD $7.46592
≥3000 USD $7.332582
Inventory: 1030
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Through Hole
Package / Case 7-SIP Module, 5 Leads
Technical
Operating Temperature -40°C~95°C With Derating
Published 2014
Series TMV-HI (1W)
Size / Dimension 0.77Lx0.30W x 0.40 H 19.5mmx7.5mmx10.2mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 1W
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Outputs 2
Efficiency 71%
Voltage - Isolation 5.2kV
Voltage - Input (Max) 5.5V
Voltage - Output 1 5V
Voltage - Input (Min) 4.5V
Current - Output (Max) 100mA 100mA
Voltage - Output 2 -5V
Compliance
RoHS Status ROHS3 Compliant
