TMR 2-1212WIN
RoHS
RoHS compliant
RoHS compliantPackage 8-SIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 12V 2W
PDF
/
Buying Options
Total Price: USD $13.76
Unit Price: USD $13.755295
≥1 USD $13.755295
≥10 USD $12.976691
≥100 USD $12.242162
≥500 USD $11.549213
≥1000 USD $10.895477
Inventory: 1079
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 9.3mm
Technical
Total Power Output-Max 2W
Current - Output (Max) 167mA
Trim/Adjustable Output NO
Input Voltage-Nom 12V
Voltage - Input (Min) 4.5V
Voltage - Output 1 12V
Output Voltage 12V
Voltage - Input (Max) 18V
Voltage - Isolation 1.5kV
Efficiency 82%
Number of Outputs 1
JESD-30 Code R-PSMA-T7
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Power (Watts) 2W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Remote On/Off, OCP, SCP
Size / Dimension 0.86Lx0.37W x 0.44 H 21.8mmx9.3mmx11.2mm
Series TMR 2WIN (2W)
Published 2014
Operating Temperature -40°C~90°C With Derating
Physical
Surface Mount NO
Package / Case 8-SIP Module, 7 Leads
Mounting Type Through Hole
Supply Chain
Factory Lead Time 11 Weeks
