TMDC 10-2425
RoHS
RoHS compliant
RoHS compliantPackage /
Category Power Supplies - External/Internal (Off-Board) / DC DC Converters
Description
DC/DC CONVERTERS +/-24V 10W
PDF
/
Buying Options
Total Price: USD $45.31
Unit Price: USD $45.31019
≥1 USD $45.31019
≥10 USD $42.745468
≥100 USD $40.325905
≥500 USD $38.043308
≥1000 USD $35.88991
Inventory: 8697
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Voltage - Output 2 -24V
Current - Output (Max) 208mA 208mA
Voltage - Input (Min) 9V
Voltage - Output 1 24V
Voltage - Input (Max) 36V
Voltage - Isolation 3kV
Efficiency 85%
Approval Agency CB, CE, cURus
Number of Outputs 2
Power (Watts) 10W
Applications ITE (Commercial)
Type Enclosed
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 3.11Lx1.34W x 0.87 H 79.0mmx34.0mmx22.0mm
Series TMDC 10 (10W)
Operating Temperature -40°C~92.5°C With Derating
Physical
Mounting Type Chassis Mount
Supply Chain
Factory Lead Time 11 Weeks
