TIM 2-2423

Traco Power
RoHS
RoHS RoHS compliant
Package 16-DIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description DC DC CONVERTER +/-15V 2W
PDF
/
Buying Options
Total Price: USD $25.94
Unit Price: USD $25.9424
≥1 USD $25.9424
≥10 USD $25.54024
≥100 USD $25.1416
≥500 USD $23.944272
≥1000 USD $21.94896
≥3000 USD $21.549862
Inventory: 45
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 14.4mm

Technical

Total Power Output-Max 2W
Voltage - Output 2 -15V
Current - Output (Max) 67mA 67mA
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Voltage - Input (Min) 18V
Voltage - Output 1 15V
Output Voltage 15V
Voltage - Input (Max) 36V
Voltage - Isolation 5kV
Efficiency 82%
Number of Outputs 2
JESD-30 Code R-PDMA-G7
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Technology HYBRID
Power (Watts) 2W
Applications Medical
Type Isolated Module
Number of Terminations 7
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Remote On/Off, OVP, SCP
Size / Dimension 0.96Lx0.57W x 0.40 H 24.3mmx14.4mmx10.2mm
Series TIM 2 (2W)
Operating Temperature -40°C~95°C With Derating

Physical

Surface Mount YES
Package / Case 16-DIP Module, 7 Leads
Mounting Type Through Hole

Supply Chain

Factory Lead Time 13 Weeks
