TIM 2-0915SM
RoHS
RoHS compliant
RoHS compliantPackage 16-SMD Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 24V 2W
PDF
/
Buying Options
Total Price: USD $26.31
Unit Price: USD $26.312
≥1 USD $26.312
≥10 USD $25.91072
≥100 USD $25.505568
≥500 USD $24.290816
≥1000 USD $22.26664
≥3000 USD $21.861805
Inventory: 78
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 24.3mm
Technical
Current - Output (Max) 83mA
Trim/Adjustable Output NO
Input Voltage-Nom 9V
Voltage - Input (Min) 4.5V
Voltage - Output 1 24V
Output Voltage 24V
Voltage - Input (Max) 12V
Voltage - Isolation 5kV
Efficiency 81%
Number of Outputs 1
JESD-30 Code R-PDMA-G7
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Technology HYBRID
Power (Watts) 2W
Applications Medical
Type Isolated Module
Number of Terminations 7
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Part Status Active
Feature Remote On/Off, OVP, SCP
Size / Dimension 0.96Lx0.57W x 0.40 H 24.3mmx14.4mmx10.2mm
Series TIM 2SM (2W)
Operating Temperature -40°C~95°C With Derating
Physical
Surface Mount YES
Package / Case 16-SMD Module, 7 Leads
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 13 Weeks
