THN 15-4822WI
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-12V 15W
PDF
/
Buying Options
Total Price: USD $41.66
Unit Price: USD $41.66174
≥1 USD $41.66174
≥10 USD $39.30353
≥100 USD $37.0788
≥500 USD $34.98
≥1000 USD $33
≥3000 USD $31.13208
Inventory: 1154
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mounting Type Through Hole
Package / Case 6-DIP Module
Surface Mount NO
Technical
Operating Temperature -40°C~85°C With Derating
Published 2009
Series THN 15WI (15W)
Size / Dimension 1.00Lx1.00W x 0.39 H 25.4mmx25.4mmx9.9mm
Feature Remote On/Off, OVP, SCP, UVLO
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 6
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 15W
Subcategory Other Analog ICs
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code S-MDMA-P6
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 86%
Voltage - Isolation 1.6kV
Voltage - Input (Max) 75V
Output Voltage 12V
Voltage - Output 1 12V
Voltage - Input (Min) 18V
Input Voltage-Nom 48V
Trim/Adjustable Output NO
Current - Output (Max) 625mA 625mA
Voltage - Output 2 -12V
Total Power Output-Max 15W
Dimensions
Height Seated (Max) 10.4mm
Compliance
RoHS Status ROHS3 Compliant
