THN 15-2422
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-12V 15W
PDF
/
Buying Options
Total Price: USD $36.87
Unit Price: USD $36.872
≥1 USD $36.872
≥10 USD $36.2428
≥100 USD $35.091936
≥500 USD $33.36608
≥1000 USD $31.06488
≥3000 USD $30.604675
Inventory: 84
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 10.4mm
Technical
Total Power Output-Max 15W
Voltage - Output 2 -12V
Current - Output (Max) 625mA 625mA
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Voltage - Input (Min) 18V
Voltage - Output 1 12V
Output Voltage 12V
Voltage - Input (Max) 36V
Voltage - Isolation 1.5kV
Efficiency 88%
Qualification Status Not Qualified
Number of Outputs 2
JESD-30 Code S-MDMA-P6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Subcategory Other Analog ICs
Power (Watts) 15W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Feature Remote On/Off, OVP, SCP
Size / Dimension 1.00Lx1.00W x 0.39 H 25.4mmx25.4mmx9.9mm
Series THN 15 (15W)
Published 2012
Operating Temperature -40°C~85°C With Derating
Physical
Surface Mount NO
Package / Case 6-DIP Module
Mounting Type Through Hole
Supply Chain
Factory Lead Time 13 Weeks
