THM 3-2423
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-15V 3W
PDF
/
Buying Options
Total Price: USD $36.7
Unit Price: USD $36.7048
≥1 USD $36.7048
≥10 USD $36.13016
≥100 USD $34.98352
≥500 USD $33.262944
≥1000 USD $30.968872
≥3000 USD $30.510093
Inventory: 44
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mounting Type Through Hole
Package / Case 24-DIP Module, 6 Leads
Surface Mount NO
Technical
Operating Temperature -40°C~90°C
Series THM 3 (3W)
Size / Dimension 1.25Lx0.80W x 0.40 H 31.8mmx20.3mmx10.2mm
Feature OCP, OVP, SCP
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 6
ECCN Code EAR99
Type Isolated Module
Applications Medical
Power (Watts) 3W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDMA-P6
Number of Outputs 2
Efficiency 86%
Voltage - Isolation 5kV
Voltage - Input (Max) 36V
Output Voltage 15V
Voltage - Output 1 15V
Voltage - Input (Min) 9V
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Current - Output (Max) 100mA 100mA
Voltage - Output 2 -15V
Total Power Output-Max 3W
Dimensions
Height Seated (Max) 10.7mm
Length 31.8mm
Compliance
RoHS Status ROHS3 Compliant
