THL 25-2413WI image
Favorite
THL 25-2413WI image
Favorite

THL 25-2413WI

Traco Power
RoHS
RoHS RoHS compliant
Package 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description DC DC CONVERTER 15V 25W
PDF
/
Buying Options
Total Price: USD $56.37
Unit Price: USD $56.370721
≥1 USD $56.370721
≥10 USD $53.179924
≥100 USD $50.16974
≥500 USD $47.329943
≥1000 USD $44.650894
Inventory: 5236
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 25.4mm
Length 25.4mm

Technical

Total Power Output-Max 25W
Current - Output (Max) 1.67A
Trim/Adjustable Output YES
Input Voltage-Nom 24V
Voltage - Input (Min) 9V
Voltage - Output 1 15V
Output Voltage 15V
Voltage - Input (Max) 36V
Voltage - Isolation 1.5kV
Efficiency 90%
Number of Outputs 1
JESD-30 Code S-MDMA-P6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Additional Feature PACKAGE ALSO AVAILABLE WITH HEATSINK
Power (Watts) 25W
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 6
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Remote On/Off, OVP, SCP
Size / Dimension 1.00Lx1.00W x 0.40 H 25.4mmx25.4mmx10.2mm
Series THL 25WI (25W)
Published 2014
Operating Temperature -40°C~80°C With Derating

Physical

Surface Mount NO
Package / Case 6-DIP Module
Mounting Type Through Hole

Supply Chain

Factory Lead Time 11 Weeks
