THL 15-4822WI
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC CONVERTER +/-12V 15W
PDF
/
Buying Options
Total Price: USD $27.02
Unit Price: USD $27.0248
≥1 USD $27.0248
≥10 USD $26.6068
≥100 USD $26.191264
≥500 USD $24.944128
≥1000 USD $22.86548
≥3000 USD $22.44975
Inventory: 33
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Voltage - Output 2 -12V
Current - Output (Max) 625mA 625mA
Voltage - Input (Min) 18V
Voltage - Output 1 12V
Voltage - Input (Max) 75V
Voltage - Isolation 1.8kV
Efficiency 90%
Number of Outputs 2
Power (Watts) 15W
Applications ITE (Commercial)
Type Isolated Module
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Remote On/Off, OCP, OVP, SCP
Size / Dimension 1.00Lx1.00W x 0.40 H 25.4mmx25.4mmx10.2mm
Series THL 15WI (15W)
Operating Temperature -40°C~70°C
Physical
Package / Case 6-DIP Module
Mounting Type Through Hole
Supply Chain
Factory Lead Time 1 Weeks
