THL 10-2423
RoHS
RoHS compliant
RoHS compliantPackage 5-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-15V 10W
PDF
/
Buying Options
Total Price: USD $30.4
Unit Price: USD $30.404
≥1 USD $30.404
≥10 USD $28.73992
≥100 USD $28.291296
≥500 USD $26.944016
≥1000 USD $24.698608
≥3000 USD $24.249562
Inventory: 1181
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 10.7mm
Technical
Total Power Output-Max 10W
Voltage - Output 2 -15V
Current - Output (Max) 333mA 333mA
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Voltage - Input (Min) 18V
Voltage - Output 1 15V
Output Voltage 15V
Voltage - Input (Max) 36V
Voltage - Isolation 1.5kV
Efficiency 89%
Number of Outputs 2
JESD-30 Code S-MDMA-T6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology HYBRID
Power (Watts) 10W
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 6
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature SCP
Size / Dimension 1.00Lx1.00W x 0.40 H 25.4mmx25.4mmx10.2mm
Series THL 10 (10W)
Published 2014
Operating Temperature -40°C~80°C With Derating
Physical
Surface Mount NO
Package / Case 5-DIP Module
Mounting Type Through Hole
Supply Chain
Factory Lead Time 11 Weeks
