THL 10-2422
RoHS
RoHS compliant
RoHS compliantPackage 5-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-12V 10W
PDF
/
Buying Options
Total Price: USD $28.05
Unit Price: USD $28.048873
≥1 USD $28.048873
≥10 USD $26.4612
≥100 USD $24.963396
≥500 USD $23.550371
≥1000 USD $22.217332
Inventory: 4046
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Through Hole
Package / Case 5-DIP Module
Surface Mount NO
Technical
Operating Temperature -40°C~80°C With Derating
Published 2014
Series THL 10 (10W)
Size / Dimension 1.00Lx1.00W x 0.40 H 25.4mmx25.4mmx10.2mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 6
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 10W
Technology HYBRID
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code S-MDMA-T6
Number of Outputs 2
Efficiency 88%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 36V
Output Voltage 12V
Voltage - Output 1 12V
Voltage - Input (Min) 18V
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Current - Output (Max) 416mA 416mA
Voltage - Output 2 -12V
Total Power Output-Max 10W
Dimensions
Height Seated (Max) 10.7mm
Compliance
RoHS Status ROHS3 Compliant
