THL 10-1222
RoHS
RoHS compliant
RoHS compliantPackage 5-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-12V 10W
PDF
/
Buying Options
Total Price: USD $29.04
Unit Price: USD $29.03697
≥1 USD $29.03697
≥10 USD $27.39337
≥100 USD $25.8428
≥500 USD $24.38
≥1000 USD $23
≥3000 USD $21.69811
Inventory: 1135
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Through Hole
Package / Case 5-DIP Module
Surface Mount NO
Technical
Operating Temperature -40°C~80°C With Derating
Published 2014
Series THL 10 (10W)
Size / Dimension 1.00Lx1.00W x 0.40 H 25.4mmx25.4mmx10.2mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 5
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 10W
Subcategory Other Analog ICs
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Number of Functions 1
JESD-30 Code S-MDMA-P5
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 87%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 18V
Output Voltage 12V
Voltage - Output 1 12V
Voltage - Input (Min) 9V
Input Voltage-Nom 12V
Trim/Adjustable Output NO
Current - Output (Max) 416mA 416mA
Voltage - Output 2 -12V
Total Power Output-Max 10W
Dimensions
Height Seated (Max) 10.7mm
Compliance
RoHS Status ROHS3 Compliant
